Diesel Fuel Filtration Considerations

Today's advanced common rail diesel engines rely on their diesel fuel filtration system  to make sure they can do their job to their peak performance.  But there’s more to diesel fuel filtration than meets the eye.  Here are some things to consider.

More Advanced Diesel Engines = Greater Chance of Damage

Most new Tier IV diesel engines today (and from this point on) are high-pressure common rail designs – highly advanced, much more efficient, and cleaner than diesels of the past.  Their injectors have extremely high pressure approaching 37,000 psi. Contrast that to the older diesel engine designs where injector pressures topped out at below 8,000.

The higher the injector pressure, the more sensitive the injectors are to damage from even the smallest particulate coming in from the fuel. Even the smallest particles can groove and score the inside of the injector. Water contamination can cause corrosion over time and possibly cause damage from steam formation inside the injector. Contaminants from microbial growth in the fuel and storage are another source of damage.

It’s the job of the fuel filtration system to make sure as few of these reach the injectors as possible. It has to function well in order to prevent these contaminants from damaging the engine.

Change In ISO Standards for Fuel Cleanliness

Because today's engines require cleaner fuel, the ISO standards that help define fuel cleanliness have also gotten stricter.

As of 2022, ISO Cleanliness Code 4406 defined the allowable standards for a number of particles of a given size per milliliter (mL) of fluid.  ISO 4406 uses a scale to specify the number of different-sized particles allowed per mL - 4 microns, 6 microns, and 14 microns. The scale runs from 6 to 22, with the larger numbers representing more particles per mL. A scale number of 22 would be 20,000 – 40,000 particles (of a given size) per mL, a scale of 20 would be 5,000 – 10,000, 16 would be 320 – 640, and so on until you get the scale number 6 is less than one particle per mL. You will usually see ISO ratings written as a series of three numbers, representing the previously-mentioned 4-6-14 micron particles.

We can see how the fuel cleanliness standards have dramatically changed by seeing how these ISO standards have changed. The World Wide Fuel Charter specifies an ISO rating of 18/16/13.  This means, per mL, diesel fuel can have 1,300 – 2,500 particles of 4 microns and up (that’s the 18).  It can’t have more than 40 - 80 particles per mL larger than 14 microns.

The fuel injector OEMs, however, differ from the Fuel Charter in recommending stricter standards, which are an ISO level of 12/9/6. Now, for particles of 4+ microns, the maximum has gone down to 20 – 40 per mL (it was 1,300 – 2,500). For particles of 14+ microns, the ceiling is reduced from 40-80 per mL (the old 13 scale number) to just less than 1 per mL.

The injector OEMs feel confident that such a dramatic reduction in allowable particulate better meets the needs for high quality and high effectiveness fuel filtration paramount.

Judging Filter Effectiveness

What’s the best way to assess the effectiveness or performance of your filtration? There are several specs commonly referenced but they don’t all tell you equally useful things.

There’s the filter’s Nominal Rating, which is an arbitrary size value that’s given to a filter. It doesn’t really have any basis with the filter’s actual performance, which means it is pretty much useless.

Absolute Ratings are a step up from nominal because they tell you the largest possible particle that could pass through the filter. As such, they correlate to the size of the largest opening in the filter media. Still, this doesn’t give you as much information as you would want.  It’s fine if a filter won’t let any particles larger than 20 microns pass through. But how many of the smaller particles is it letting through? What proportion of the does it catch? If you’re trying to filter diesel fuel so that it meets ISO 12/9/6 (no more than 20-40 particles per mL larger than 4 microns), knowing that the filter has an Absolute rating is 10 microns doesn’t tell you anything meaningful.

Beta Rating is what you need to know. It tells you the ratio between the particles of a given size before and after filtration. In other words, the proportion of particles of a given size that your filter is going to stop.  Beta Rating is always expressed in terms of particle size because the same filter can have different beta ratings for different particle sizes (in other words, a filter isn’t always equally effective at stopping all different particle sizes below its Absolute Rating).

Let’s say a fuel filter has a beta rating of 10 at 4 microns.  This means that for every 10 particles 4 microns or larger that are in the fuel before the filter, once the fuel goes through the filter, you’ll have one particle remaining. The filter caught 90% (nine out of ten). The 90% would be the fuel filter’s Efficiency Rating.

So if we relate this to the issue of the need for fuel to meet the ISO 4406, we realize that there have to be two elements in sync to meet the standard. You want to have as low a number of particles in the fuel to begin with, and you need to have a filter with a high enough Beta Rating to take out enough particles such that the filtered fuel meets the standard.

What if you had older diesel fuel that met the old ISO 4406 standard, but you wanted to use it in an engine that required the new standard?

The old ISO 4406 allows for 1,300 – 2,500 particles larger than (or equal to) 4 microns. We’ll split the difference and call it 1,900.  The new ISO standards allow for only 30 such particles (between 20 and 40 per mL).  So your filter beta rating would need to be 63.3 at 4 microns.

However, you’d be fine within a range of ratings, because those ISO ratings of particle count are ranges themselves. To go from a maximum of 2,500 particles to the minimum range of 20, that would take a beta rating of 125.  To go from the minimum old range of 1,300 to the maximum allowed range of 40, you’d need a beta rating of 32.5.  So you’re likely to be okay with a filter Beta Rating of anywhere between 32 and 125. Assuming, of course, that the beta ratings for the other two particle sizes (6 microns and 14 microns) also met the standard.
